Short-Wave IR Imaging Module(SW640)

Description：

1.Provides crisp image under all types of light environment

2.On-board CDS to reduce noise

3.Mulitple gain mode is dedicated to low light environment

4.>70% quantum efficiency

5.Automatically integral control

6.Up to 300 Hz frame rate

Specification：

Size (L ×W ×H)：50mm ×50mm ×57mm  (lens not included)

18.Weight：≤ 190 g  (lens not included)

Technical Parameters：

1.Detector Type：SWIR InGaAs, 640×512/ 15μm

2.Spectral Range：0.9 ~ 1.7 μm

3.Quantum Efficiency> 70%

4.Integral Mode：Snapshot

5.Brightness/Contrast：Auto/Manual adjustment

6.Image Pattern ：White hot/ Black hot

7.Digital Zooming：1~8× continuous, step 0.1

8.Image Rollover：Normal/ Horizontal/ Vertical/ Base point

9.Image Processing：ATI, Stripe filtering, Particle filtering, Timing filtering, HDR, DDE, NUC etc

10.Start-up Time：5 s

11.Power Supply：DC 6-12 V

12.Typical Consumption：< 12W (with TEC) @25 oC

13Communications：RS422, 115200 bps

14.Video Output：CameraLink-Base 8/14 bits, 1~300 Hz; Analog (optional)

15.Lens Interface：C-Mount

16Lens：Customization

17.Size (L ×W ×H)：50mm ×50mm ×57mm  (lens not included)

18.Weight：≤ 190 g  (lens not included)

19.Operating Temp.：-40 oC ~ +60 oC

20.Storage Temp.：- 45 oC ~ +70 oC
